StateKit

Type-safe async state machine with built-in logging and SwiftUI bindings

Requirements

• Swift >= 6.0
• macOS 13+ / iOS 16+ / tvOS 16+ / watchOS 9+

Installation

Add to your Package.swift:

dependencies: [
    .package(url: "https://github.com/philiprehberger/swift-state-kit.git", from: "0.21.0")
]

Then add "StateKit" to your target dependencies:

.target(name: "YourTarget", dependencies: [
    .product(name: "StateKit", package: "swift-state-kit")
])

Usage

import StateKit

// Define states and events
enum OrderState: Hashable, Sendable {
    case pending, confirmed, shipped, delivered
}

enum OrderEvent: Hashable, Sendable {
    case confirm, ship, deliver
}

// Define transitions
let machine = StateMachine(
    initial: OrderState.pending,
    transitions: [
        Transition(from: .pending, on: .confirm, to: .confirmed),
        Transition(from: .confirmed, on: .ship, to: .shipped),
        Transition(from: .shipped, on: .deliver, to: .delivered)
    ]
)

let state = try await machine.send(.confirm)  // => .confirmed

Builder DSL

import StateKit

let machine = StateMachine<OrderState, OrderEvent>(initial: .pending) {
    Transition(from: .pending,   on: .confirm, to: .confirmed)
    Transition(from: .confirmed, on: .ship,    to: .shipped)
    Transition(from: .shipped,   on: .deliver, to: .delivered)

    // Multi-source helper expands into one transition per source
    Transition.from([.pending, .confirmed, .shipped], on: .cancel, to: .cancelled)
}

The @TransitionBuilder result builder also supports if, if let, if/else, and for blocks inside the closure.

Waiting for a State

import StateKit

// Suspend until the machine reaches .delivered (optionally with a timeout)
let final = try await machine.waitFor(.delivered, timeout: .seconds(60))

Returns immediately if the machine is already in the target state. Throws StateMachineError.waitTimeout if the optional duration elapses first.

Previewing a Transition

import StateKit

// Resolve where an event *would* lead — honoring guards — without transitioning
if let next = await machine.peek(.confirm) {
    print("Confirm would move to \(next)")
}

peek(_:) runs the same matching and guard logic as send(_:) but never mutates state, runs side effects, or records history. Returns nil if no transition applies. Unlike canSend(_:), it evaluates guard conditions and returns the destination state.

Sending a Sequence of Events

import StateKit

// Apply several events in order, returning the final state
let final = try await machine.send([.confirm, .ship, .deliver])  // => .delivered

Events are applied one at a time. If an event is invalid in the state reached so far, send(_:) throws and the events applied before it remain committed.

Sending Without Throwing

import StateKit

// Returns nil instead of throwing when the event does not apply in the current state
if let next = try await machine.sendIfPossible(.confirm) {
    print("Moved to \(next)")
}

sendIfPossible(_:) behaves exactly like send(_:) when a transition matches — side effects, middleware, entry/exit actions, and history all run. Only StateMachineError.invalidTransition is swallowed; side effect failures still throw.

Async Side Effects

Transition(from: .pending, on: .confirm, to: .confirmed, sideEffect: {
    try await sendConfirmationEmail()
})

Label the closure sideEffect: — an unlabeled trailing closure binds to guard: instead.

Logging

let machine = StateMachine(
    initial: OrderState.pending,
    transitions: transitions,
    logger: .console
)
// Logs: "[StateKit] pending --confirm--> confirmed"

Timeout Transitions

import StateKit

// Auto-transition to error after 30 seconds in loading state
await machine.addTimeout(TimeoutTransition(
    from: .loading, after: .seconds(30), on: .timeout, to: .error
))

Timeouts auto-cancel if the state changes before the duration expires.

Transition Metrics

import StateKit

let machine = StateMachine(initial: OrderState.pending, transitions: transitions, enableMetrics: true)
try await machine.send(.confirm)

let metrics = await machine.metrics
metrics?.totalTransitions                            // 1
metrics?.transitionCount(from: .pending, on: .confirm)  // 1
metrics?.eventCount(.confirm)                        // count across every source state
metrics?.allTransitionCounts                         // every transition, most frequent first
metrics?.mostFrequentTransition                      // the hottest transition, if any
metrics?.timeInState(.confirmed)                     // includes the visit in progress

Diagram Export

import StateKit

print(await machine.exportMermaid())  // stateDiagram-v2, renders as-is in Markdown
print(await machine.exportDOT())      // Graphviz DOT

Both exports mark the initial state and highlight the current one. State descriptions containing spaces or punctuation are sanitized for Mermaid and escaped for DOT, and wildcard transitions leave an anyState pseudo-state rather than Mermaid's [*] start marker.

State Persistence

import StateKit

// Save state
let snapshot = await machine.snapshot()
let data = try JSONEncoder().encode(snapshot)

// Restore state
let decoded = try JSONDecoder().decode(StateMachineSnapshot<OrderState>.self, from: data)
try await machine.restore(from: decoded)

Middleware

import StateKit

struct AuthMiddleware: TransitionMiddleware {
    func intercept(
        from: OrderState, event: OrderEvent, to: OrderState,
        next: @Sendable () async throws -> Void
    ) async throws {
        guard await isAuthorized() else { throw AuthError.denied }
        try await next()
    }
}

await machine.addMiddleware(AuthMiddleware())

Middleware runs in order. Each must call next() to proceed or throw to reject.

Entry and Exit Actions

import StateKit

let machine = StateMachine(initial: OrderState.pending, transitions: transitions)

await machine.onEnter(.shipped) {
    try await sendTrackingNotification()
}

await machine.onExit(.pending) {
    try await logOrderStart()
}

Exit actions run before the state changes, entry actions run after.

Async State Streams

import StateKit

let machine = StateMachine(initial: OrderState.pending, transitions: transitions)

// Observe state changes reactively
Task {
    for await state in await machine.stateStream {
        print("State changed to: \(state)")
    }
}

// Or observe full transitions
Task {
    for await (from, event, to) in await machine.transitionStream {
        print("\(from) --\(event)--> \(to)")
    }
}

Wildcard Transitions

import StateKit

// Matches from any state — useful for global events like reset
let transitions = [
    Transition(from: .idle, on: .start, to: .loading),
    Transition(from: .loading, on: .succeed, to: .loaded),
    Transition(fromAny: .reset, to: .idle)  // works from any state
]

Specific transitions are always checked before wildcards.

Guard Conditions

import StateKit

let transitions = [
    Transition(from: .idle, on: .start, to: .loading, guard: { await isNetworkAvailable() }),
    Transition(from: .idle, on: .start, to: .error, guard: { true })  // fallback
]

When multiple transitions match the same state and event, guard conditions are evaluated in order. The first transition whose guard returns true is taken.

State History and Undo

import StateKit

let machine = StateMachine(
    initial: OrderState.pending,
    transitions: transitions,
    historyDepth: 0  // 0 = unlimited, nil = disabled
)

try await machine.send(.confirm)
try await machine.send(.ship)

// Inspect history
let history = await machine.history  // [pending→confirmed, confirmed→shipped]

// Undo last transition
let restored = try await machine.undo()  // => .confirmed

SwiftUI Integration

struct OrderView: View {
    @State private var machine: ObservableStateMachine<OrderState, OrderEvent>?

    var body: some View {
        if let machine {
            VStack {
                Text("Status: \(machine.state)")
                Button("Confirm") { Task { try await machine.send(.confirm) } }
            }
        }
    }
}

API

StateMachine

Method	Description
init(initial:transitions:logger:historyDepth:enableMetrics:)	Create a state machine with initial state and transitions
send(_:)	Send an event to trigger a transition
send(_:) (array)	Send a sequence of events in order, returning the final state
sendIfPossible(_:)	Send an event, returning nil instead of throwing when no transition applies
peek(_:)	Resolve the destination state for an event (honoring guards) without transitioning
canSend(_:)	Check if an event is valid in the current state
waitFor(_:timeout:)	Suspend until the machine reaches a target state, with optional timeout
undo()	Revert to the previous state (requires history)
onTransition(_:)	Register a callback for state changes
onEnter(_:perform:)	Register an action for when a state is entered
onExit(_:perform:)	Register an action for when a state is exited
addMiddleware(_:)	Add a middleware to the transition pipeline
reset()	Reset to initial state, clearing history
validEvents	Set of events valid in the current state
validEvents(for:)	Set of events valid for a given state
validate()	Check transition table for duplicates, terminal states, and unreachable states
snapshot()	Create a Codable snapshot of the current state
restore(from:)	Restore state from a snapshot
addTimeout(_:)	Register an automatic timeout transition
metrics	Transition metrics (if enabled)
resetMetrics()	Reset metrics counters
exportDOT()	Export transition graph as Graphviz DOT
exportMermaid()	Export transition graph as a Mermaid stateDiagram-v2
attach(child:to:)	Attach a child state machine to a parent state
currentState	The current state
initialState	The initial state the machine was created with
history	Array of past transitions
canUndo	Whether an undo operation is available
stateStream	AsyncStream<State> emitting new states after transitions
transitionStream	AsyncStream of (from, event, to) tuples

TransitionMetrics

Property/Method	Description
totalTransitions	Total number of transitions recorded
transitionCount(from:on:)	Count for one specific transition
eventCount(_:)	Count for an event across every source state
allTransitionCounts	Every recorded transition with its count, most frequent first
mostFrequentTransition	The most frequently taken transition, or nil
timeInState(_:)	Total time in a state, including the visit in progress
reset()	Clear all counters and timings

TransitionValidation

Property	Description
duplicates	Transitions sharing a (from, event) pair without guards
terminalStates	States reachable as a target with no outgoing transitions
unreachableStates	States in the table that cannot be reached from the initial state
isValid	Whether the table has no duplicates

Transition

Property	Description
init(from:on:to:guard:sideEffect:)	Create a transition from a specific state
init(fromAny:to:guard:sideEffect:)	Create a wildcard transition from any state
from(_:on:to:guard:sideEffect:)	Static helper expanding a list of source states into one transition each
from	Source state (nil for wildcard)
event	Triggering event
to	Destination state
guardCondition	Optional async predicate that must return true for the transition
sideEffect	Optional async closure executed during transition

StateMachine builder init

Init	Description
init(initial:logger:historyDepth:enableMetrics:_:)	Convenience initializer accepting a @TransitionBuilder closure

ObservableStateMachine

Property/Method	Description
init(machine:)	Create wrapper, reading initial state from the machine
init(machine:initialState:)	Create wrapper with explicit initial state
state	Current state (observable)
isTransitioning	Whether a transition is in progress
send(_:)	Send an event
canSend(_:)	Check if an event is valid
undo()	Revert to the previous state
canUndo	Whether an undo operation is available

Development

swift build
swift test
